Stainless steel woven mesh is a woven stainless steel wire mesh in plain, twill and Dutch weaves, for filtering and separating gases and liquids.
Stainless steel wire woven like cloth into a fine net, used to filter gases and liquids.
Choose This Product When
- You need a filter mesh for gas or liquid
- You need heat and corrosion resistance
- You need a specific mesh size or weave
Types
Plain weave
Twill weave
Dutch (dense) weaveProduct Description
Stainless steel woven mesh is heat-, acid-, corrosion- and wear-resistant. It is mainly used for gas and liquid filtration and other separation. The surface is smooth, rust-free, non-toxic and hygienic.
Stainless steel mesh is available in plain, twill and Dutch weave – Dutch weave for fine filtration – from mesh 4 to 200.
How It Works
Wires are woven over and under each other like cloth. Plain weave gives a simple square opening, twill weave is stronger and allows finer mesh, and Dutch (dense) weave packs the wires tightly for very fine filtration. The mesh number is the number of openings per inch.
Features
- Plain, twill and Dutch (mat) dense weaves
- Mesh 4 to 200
- Flat surface, even gaps, stable quality
Applications
- Petroleum and chemical industry
- Water and sewage treatment
- Food and pharmaceutical industry
- Solid-liquid separation and screening
Often Used in These Industries
Materials
- SUS 201, 302, 304, 304L, 316, 316L, 310, 310S
Frequently Asked Questions
Plain, twill or Dutch weave – what is the difference?
Plain weave is the simplest and most common. Twill weave is stronger and allows finer mesh. Dutch weave gives very fine filtration with high strength.
What does "mesh 4–200" mean?
The number of openings per inch. A higher number means finer mesh.
Which steel grades are available?
SUS 201, 302, 304, 304L, 316, 316L, 310 and 310S.
